Description
*Tips:
1.This car multimedia player is compatible with all cars. Please check the Installation Dimension;
2.The installation requires a little knowledge of electronic products. Please install it with the help of professional;
3. After receiving the product, please try to check whether the machine is normal, and then install it (testing method: connect red and yellow lines to the positive pole and black line to the negative pole of the 12V power supply). When installing, please be careful not to connect the line incorrectly, so as not to affect the normal use. When connecting speaker wires, pay attention to the positive and negative poles.
*Features:
This product not included GPS function, support mirror link phone map, only support Android phone mirror link
1. 7" High Digital resistive touch screen, 1024*600
2. Support the Audio playback format of MP3/WMA/WAV/FLAC/APE etc
3. Support the Video playback format of RM/RMVB/MP4/FLV/MKV/3GP/AVI/ASF/SWFMP1/MP2 etc
4. With Front USB2.0 port and TF card slot
5. BT function,free hand call and BT music
6. FM stereo Radio
7. Full IR remote control
8. Power-off with auto-memory store function under radio or TF/USB mode
9. Clock function
10. Mute function
11. Bass+ Treble, L+R channel stabilizer
12. Front AUX in function
*Specifications:
Model: 9601
Type: MP5 player
System: wince
Decoder chip: C500
Screen size: 7 inches
Screen resolution: 1024*600
Panel size: 189mm x 57mm
Host depth: 186mm
Radio band: FM1/FM2/FM3, AM1/AM2
Radio chip: QN8035
Language:English/Chinese/Spanish/Portuguese/Russian/Italian/German/French/Turkish/Czech/Arabic/Polish/Hebrew
Brake prompt: yes
Bluetooth: support
Amplifier chip: TDA7388
Radio frequency: FM 87.5MHZ-108MHZ, AM 522HZ-1620HZ
External memory card slot: mini TF card
Remote control: yes
USB port: support USB 2.0
Reset button: NO
RCA video terminal: 2-channel video output, 1-channel reversing input, 2-channel audio output, 1-channel video input
Volume knob: yes
Supported audio formats: MP3/WMA/WAV/OGG/FLAC/APE
Supported video Formats: RM/RMVB/MP4/FLV/MKV/3GP/AVI/ASF/SWFMP1/MP2
Supported image formats: JPG
*Packing List:
1 x Car MP5 Player
1 x Remote Control
1 x Connector Wire
1 x User Manual
2 x Bracket
1 X backup camera (Optional)
